The brief
A cafe operator on the Australian coast was rebuilding the front of a beachfront venue — a new awning over the entry and the outdoor seating, repainted render, and a stripped-back interior. What the rebuild did not solve was how the building read to people walking the promenade. From the footpath the cafe was anonymous by day and completely dark after sunset, in a strip where every other venue carries some kind of light.
The operator wanted two things. First, a soft neon piece inside — flexible lettering over the espresso bar that would photograph well and give the room a warm evening glow without turning it into a nightclub. Second, wording on the new awning: illuminated letters fixed to the underside of the awning frame, so the shopfront reads from both directions along the promenade and the light lands on the pavement instead of shining up into the apartments above.
The environment was the real constraint. The site sits a few metres from salt water, with a constant onshore breeze, salt spray, strong UV and afternoon heat. Anything mounted outdoors there has to survive a marine atmosphere, and the pieces under the awning occupy the one part of the building that stays damp and shaded all day — so condensation and corrosion protection mattered more than raw brightness.
What we built
Three pieces, produced from a single artwork pack so they share one type style and one light temperature. The neon is the venue’s signature; the letters carry it out to the street.
- Interior neon: custom-shaped LED neon flex on a clear acrylic backing, traced from the venue’s own hand-lettered wordmark
- Awning letters: front-lit illuminated letters with 3D-carved faces, mounted on the underside of the awning frame over the entry and the seating edge
- Secondary letters: back-lit stainless steel letters for the fascia section beside the entrance, where the awning does not reach
- Materials: LED neon flex on acrylic backing for the soft interior piece; acrylic with 3D carving and front-facing LEDs for the awning letters; stainless steel with an electroplated finish and LED backlighting for the externally exposed fascia letters
- Electrical: 12V LED neon flex on a remote driver inside the shopfront joinery, keeping the low-voltage connections out of the salt-air run
- Coastal protection: electroplated stainless steel specified for the weather-exposed letters because it is corrosion and weather resistant, plus sealed cable glands and UV-resistant faces across the set
- Lighting character: warm white throughout, set to read clearly from the promenade without spilling into the first-floor windows
- Mounting: pre-drilled backings on stud fixings, with 1:1 paper templates and a wiring diagram supplied for the builder
How the project ran
The rebuild was already underway when we were brought in, so the first job was measuring against a facade that kept changing — the awning frame went up before the render was finished, and the finished ground level at the entry moved by a few centimetres during paving. We worked from site photographs, the awning’s own fabrication drawings and a set of dimensions confirmed at the frame, then issued a scaled layout showing each piece in position and how the text would read from either end of the promenade.
The awning letters carried the most risk. Underside mounting means the characters are only ever seen at an angle, and the drop to the pavement is fixed by the awning height, so light output and letter depth had to be set against that geometry rather than a showroom sample. That is what keeps the front illumination even across each character, whether it is viewed from a metre away or from across the road.
The material call was made early. For the letters exposed to direct weather we specified electroplated stainless steel rather than a painted finish, because salt air and UV dull an unprotected surface long before the LEDs reach the end of their working life. For the sheltered pieces under the awning we kept the front-lit acrylic construction, which gives the softer, more even letter face the operator wanted for a cafe.
Because the venue kept trading through the fit-out, we produced one full-size prototype letter for the awning set and signed off stroke weight, colour temperature and finish against the painted render before the rest of the set went into production.
Delivery and installation
The finished pieces shipped by air freight in individual crates, with mounting hardware, remote drivers, wiring diagram and installation notes packed alongside them. The client’s own builder installed everything, which let the trades work to their own programme instead of closing the cafe for a separate fit-out window.
Every piece was supplied with a 1:1 template so the awning fixings could be marked out and drilled once, on a frame that is awkward to reach from a ladder. The remote driver for the interior neon sits inside the joinery rather than behind the acrylic face, so the low-voltage connections stay away from the damp underside of the awning and any future change to the bar wall is a sign-off rather than an electrical job.
Outcome
The cafe now reads from both directions along the promenade and stays visible well after the last of the daylight goes. The soft neon gives the interior a warm, photographable focal point at the espresso bar without overwhelming a small room, while the awning letters light the entry and the seating edge from above — making the shopfront legible at a glance without throwing light into the neighbouring apartments.
Choosing electroplated stainless steel for the exposed letters also means the set should hold its finish through coastal summers rather than pitting and fading after the first season. The operator holds the approved production files for every piece, so a damaged character or a future second site can be ordered against the original artwork and match the existing signage exactly.
The pieces used on this project are the custom shaped neon lights, the front-lit resin letter signs and the stainless steel back-lit letter signs.
